    Mașină de laminat de format mare

    Product Description

    Producător: PAMA

    Model: Servo Type


    SPECIFICATIONS CS 1316 CS 1416 CS 1616 CS 1816
    Max. Sheet Size W x L 1300 x 1300 mm 1450 x 1450 mm 1650 x 1650 mm 1850 x 1650 mm
    Min. Sheet Size W x L 450 x 450 mm 450 x 450 mm 550 X 550 mm 600 X 600 mm
    Thickness of Litho Sheet 120 — 800 mm 120 — 800 mm 150 — 800 mm 180 — 800 mm
    Thickness of Substrate Sheet 0.5 — 10 mm 0.5 — 10 mm 0.5 — 10 mm 0.5 — 10 mm
    Machine Speed 150 m/min 150 m/min 150 m/min 150 m/min
    Machine Speed 10000 Sheets/h 9000 Sheets/h 8000 Sheets/h 7000 Sheets/h
    Typical Speed 8000 Sheets/h 7200 Sheets/h 6400 Sheets/h 5600 Sheets/h
    Accuracy ±1.5 mm ±1.5 mm ±1.5 mm ±1.5 mm
    10050 x 2394 x 2180 mm 12515 x 2544 x 2180 12515 x 2740 x 2180 12515 x 2940 x 2180
    Options: Flip Flop Stacker, Auto Cardboard Laminating Machine
